Digital Pressure Gauge YK120B Durable Stainless Steel Housing with Large Backlit LCD for Accurate Pressure Readings

Name: Digital Pressure Gauge YK120B Durable Stainless Steel Housing with Large Backlit LCD for Accurate Pressure Readings
Brand: Yunyi
Price: 686 USD

Supply Ability : 5000 pieces/year

Working Temperature : -20~50℃

Backlight Color : Blue , some is white

Environment Temperature : -20～70 ℃

Color : Black,Grey,Beige,Brown,Red,Blue etc

Diaphragm Material : acid, corrosion

Price : $686, 10-499 pieces

Electric Protection : Short-circuit protection

Element Material : 304SS,316L

Surface Finish : Immersion Gold

Range : -0.1~0~100MPa

Port Size : 1/4 inch NPT

Connection Material : SS316L

Board Diameter : 250*250mm

Certification : CE/RoHs

Operating Temperature : -10°C to 50°C

Material : Stainless steel housing

Packaging Details : Carbon box

Brand Name : Yunyi

Place of Origin : China

Overload Capacity : 1.5 times full

Model Number : YK-120B

MOQ : 1

Delivery Time : 10 working days

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Contact Now

Product Description

The YK120B digital pressure gauge is a high-precision, battery-powered or externally powered instrument designed for reliable pressure measurement in both laboratory and industrial environments. Featuring a large 5-digit LCD display with backlight, the YK120B provides clear readings even in low-light conditions. Its stainless steel housing (304 or 316) ensures excellent durability and protection against harsh environments, with an IP65 minimum ingress protection rating.

The gauge delivers outstanding accuracy of ±0.05% FS (optional ±0.02% FS) and supports multiple switchable pressure units, including kPa, Bar, psi, MPa, kgf/cm², and mmHg. For system integration, optional outputs such as 4–20 mA analog, RS485 Modbus RTU, and data logging are available.

The YK120B is simple to operate, offers long-term stability, and requires minimal maintenance. Its zero-point calibration function allows users to easily adjust the gauge on site, ensuring consistent performance over time.

Digital Pressure Gauge YK120B Durable Stainless Steel Housing with Large Backlit LCD for Accurate Pressure Readings

Application Range

The YK120B digital pressure gauge is widely used in:

Hydraulic & pneumatic systems – monitoring pump output, filter differential pressure, and cylinder pressure
Water treatment & plumbing – measuring line pressure in water supply, booster stations, and irrigation systems
Oil & gas industry – compatible with non-corrosive and mildly corrosive media such as gas, air, and hydraulic oil
Laboratory & calibration – ideal for precision testing, pressure calibration, and research experiments
HVAC & refrigeration – checking refrigerant pressure and system performance
Industrial machinery – pressure monitoring on compressors, presses, and process equipment

With its combination of accuracy, durability, and flexible output options, the YK120B is a versatile solution for most pressure measurement needs.
